Interactive Transcript Feature

Features

• Auto-Scrolling - Transcript automatically highlights and scrolls to the current line
• Click to Seek - Click any transcript line to jump to that moment in the video
• Draggable Window - Position the transcript anywhere on screen (desktop only)
• Resizable Window - Adjust transcript window size with mouse or keyboard
• Keyboard Drag Mode - Use arrow keys to move the transcript window (D key to toggle)
• Keyboard Resize Mode - Use arrow keys to resize the transcript window (R key to toggle)
• Settings Menu - Configure drag and resize modes
• Mobile Responsive - Adapts to mobile screens (< 768px) with optimized layout
• Fullscreen Support - Transcript repositions intelligently in fullscreen mode
• Search & Read - Perfect for accessibility and language learning

Quick Start

Enable Transcript

<video data-vidply data-transcript="true" data-transcript-button="true">
  <source src="video.mp4" type="video/mp4">
  <track kind="captions" src="captions.vtt" srclang="en" label="English">
</video>

<script type="module">
  import Player from './dist/prod/vidply.esm.min.js';
</script>

That's it! The transcript button will appear in the control bar.

Configuration Options

Via JavaScript

const player = new Player('#video', {
  transcript: true,              // Enable transcript feature
  transcriptButton: true,        // Show transcript button in controls
  transcriptPosition: 'external' // Position mode (currently only 'external')
});

Via Data Attributes

<video
  data-vidply
  data-transcript="true"
  data-transcript-button="true"
  src="video.mp4"
>
  <track kind="captions" src="captions.vtt" srclang="en" label="English">
</video>

How It Works

The transcript feature automatically:

1. Detects caption/subtitle tracks in your video
2. Loads the VTT (WebVTT) cue text
3. Creates an interactive, scrollable window
4. Highlights the current line based on video playback time
5. Auto-scrolls to keep the current line visible

API Methods

Show/Hide Transcript

const player = new Player('#video', {
  transcript: true,
  transcriptButton: true
});

// Show transcript window
player.transcriptManager.showTranscript();

// Hide transcript window
player.transcriptManager.hideTranscript();

// Toggle transcript visibility
player.transcriptManager.toggleTranscript();

Check State

// Check if transcript is visible
if (player.transcriptManager.isVisible) {
  console.log('Transcript is showing');
}

Programmatic Control

// Get transcript entries
console.log(player.transcriptManager.transcriptEntries);

// Get current active entry
console.log(player.transcriptManager.currentActiveEntry);

User Interaction

Click to Seek

Users can click any transcript line to jump to that moment:

// This happens automatically, but you can listen for it
player.on('timeupdate', (time) => {
  console.log('User jumped to:', time);
});

Drag & Resize Modes (Desktop)

On desktop (>= 768px), users can:

Drag Mode:

• D Key - Toggle keyboard drag mode
• Arrow Keys - Move window in 10px increments (Shift = 50px)
• Mouse Drag - Drag the transcript header to reposition
• Home Key - Reset to center position
• Escape Key - Exit drag mode

Resize Mode:

• R Key - Toggle keyboard resize mode
• Arrow Keys - Resize window in 10px increments (Shift = 50px)
• Mouse Resize - Drag resize handles at window edges
• Escape Key - Exit resize mode

Settings Menu:

• Click the settings icon (⚙️) in the transcript header
• Toggle drag mode and resize mode
• Close the transcript window

Mobile Behavior

On mobile devices (< 768px breakpoint):

• Transcript appears below the video player
• Positioned in document flow (not draggable or resizable)
• Optimized for scrolling and reading
• Minimum width: 300px

Positioning Modes

Desktop (Non-Fullscreen)

• Appears next to the video player
• Draggable to any position
• Height matches video height

Fullscreen Mode

• Positioned in bottom-right corner
• Floating over the video
• Leaves room for controls

Mobile

• Below video and controls
• Full width
• Maximum height of 400px
• Part of page flow

Keyboard Shortcuts

Global Shortcuts (Player focused)

Drag Mode (D key - must be enabled first)

Resize Mode (R key - must be enabled first)

Transcript Entries

Styling the Transcript

Custom Colors

/* Transcript window */
.vidply-transcript-window {
  background: rgba(20, 20, 30, 0.95);
  border: 1px solid rgba(255, 255, 255, 0.2);
}

/* Header */
.vidply-transcript-header {
  background: rgba(30, 30, 40, 0.95);
  border-bottom: 1px solid rgba(255, 255, 255, 0.1);
}

/* Transcript entries */
.vidply-transcript-entry {
  padding: 12px;
  border-bottom: 1px solid rgba(255, 255, 255, 0.05);
}

/* Active entry */
.vidply-transcript-entry-active {
  background: rgba(59, 130, 246, 0.2);
  border-left: 3px solid #3b82f6;
}

/* Timestamp */
.vidply-transcript-time {
  color: #60a5fa;
  font-weight: 600;
}

Complete Example

<!DOCTYPE html>
<html lang="en">
<head>
  <meta charset="UTF-8">
  <meta name="viewport" content="width=device-width, initial-scale=1.0">
  <title>Transcript Example</title>
  <link rel="stylesheet" href="dist/vidply.min.css">

  <style>
    body {
      font-family: system-ui, sans-serif;
      padding: 20px;
      background: #111;
      color: #fff;
    }

    .container {
      max-width: 1200px;
      margin: 0 auto;
    }

    h1 {
      margin-bottom: 20px;
    }

    /* Custom transcript styling */
    .vidply-transcript-window {
      background: linear-gradient(135deg, rgba(30, 30, 50, 0.98), rgba(20, 20, 40, 0.98));
      backdrop-filter: blur(10px);
    }

    .vidply-transcript-entry-active {
      background: linear-gradient(90deg, rgba(139, 92, 246, 0.2), rgba(59, 130, 246, 0.2));
    }
  </style>
</head>
<body>
  <div class="container">
    <h1>Video with Interactive Transcript</h1>

    <video
      id="my-video"
      data-vidply
      data-transcript="true"
      data-transcript-button="true"
      width="800"
      height="450"
    >
      <source src="video.mp4" type="video/mp4">
      <track kind="captions" src="captions-en.vtt" srclang="en" label="English" default>
      <track kind="captions" src="captions-es.vtt" srclang="es" label="Español">
    </video>

    <div style="margin-top: 20px;">
      <button id="toggleTranscript">Toggle Transcript</button>
    </div>
  </div>

  <script type="module">
    import Player from './dist/prod/vidply.esm.min.js';

    // Player is auto-initialized via data-vidply

    // Get player instance
    const videoElement = document.getElementById('my-video');
    const player = videoElement.vidply; // Player instance stored on the media element

    // Or find it manually
    const allPlayers = document.querySelectorAll('[data-vidply]');
    // const player = allPlayers[0].vidply;

    // Manual toggle button
    document.getElementById('toggleTranscript').addEventListener('click', () => {
      if (player && player.transcriptManager) {
        player.transcriptManager.toggleTranscript();
      }
    });

    // Listen for transcript interactions
    document.addEventListener('DOMContentLoaded', () => {
      // Wait a moment for player to initialize
      setTimeout(() => {
        const container = document.querySelector('.vidply-player');
        const video = container?.querySelector('video, audio');
        if (video && video.vidply) {
          const p = video.vidply;

          p.on('timeupdate', (time) => {
            // User can see which line is active
            if (p.transcriptManager && p.transcriptManager.currentActiveEntry) {
              console.log('Active transcript:', p.transcriptManager.currentActiveEntry.cue.text);
            }
          });
        }
      }, 1000);
    });
  </script>
</body>
</html>

Use Cases

1. Accessibility

• Screen reader users can read transcript text
• Deaf/hard-of-hearing users get full text access
• Users in noisy environments can read instead of listen

2. Language Learning

• Follow along with native speakers
• Click to replay difficult sections
• Read and listen simultaneously

3. Search & Navigation

• Quickly scan content
• Find specific topics
• Jump to relevant sections

4. Note Taking

• Reference exact quotes
• Copy text for citations
• Study aid for educational content

5. SEO & Searchability

• Video content becomes text-searchable
• Better accessibility indexing
• Improved content discovery

Requirements

Caption/Subtitle Track Required

The transcript feature requires at least one caption or subtitle track:

<track kind="captions" src="captions.vtt" srclang="en" label="English">
<!-- or -->
<track kind="subtitles" src="subtitles.vtt" srclang="en" label="English">

Note: kind="descriptions" or kind="chapters" tracks are NOT used for transcripts.

Streaming Format Support



iOS / iPadOS: Even though hls.js cannot run on iOS (no MSE), VidPly listens for addtrack / removetrack / loadedmetadata on the native HTMLMediaElement.textTracks collection and surfaces every subtitle rendition through the same captions menu and interactive transcript as on desktop. Transcript-on-iOS now works for live and adaptive HLS streams.



For DASH streams with TTML subtitles, captions are displayed on-screen by dash.js but the interactive transcript is not available. If you need transcript support with DASH, use WebVTT subtitle tracks.

WebVTT Format

Captions must be in WebVTT format:

WEBVTT

00:00:00.000 --> 00:00:05.000
Welcome to this video tutorial.

00:00:05.000 --> 00:00:10.000
Today we'll learn about VidPly's transcript feature.

00:00:10.000 --> 00:00:15.000
It's a powerful tool for accessibility and learning.

Browser Support

The transcript feature works in all modern browsers:

• Chrome/Edge 90+
• Firefox 88+
• Safari 14+
• Mobile browsers (iOS Safari, Chrome Android)

Troubleshooting

Transcript Button Not Showing

Cause: No caption/subtitle tracks detected

Solution:

<!-- Add at least one caption track -->
<track kind="captions" src="captions.vtt" srclang="en" label="English">

Transcript Shows "Loading..."

Cause: VTT file taking time to load or wrong path

Solutions:

1. Check file path is correct
2. Check CORS headers if loading from different domain
3. Verify VTT file format is valid

Can't Drag Transcript on Mobile

Expected: On mobile (< 768px), transcript is NOT draggable. It's positioned in the page flow below the video.

Transcript Not Auto-Scrolling

Cause: JavaScript error or caption track not in hidden mode

Solution: Check browser console for errors. The transcript manager automatically sets track mode to hidden.

Advanced: External Transcript Container

You can render the transcript in a custom container (future feature):

const player = new Player('#video', {
  transcript: true,
  transcriptPosition: 'external',
  transcriptContainer: '#my-transcript-container'
});

<div id="my-transcript-container"></div>

Note: This feature is partially implemented. Currently, transcript always appears next to or below the video.

Performance Notes

• Transcript entries are created on-demand when transcript is first shown
• Auto-scrolling uses efficient scrollIntoView; the smooth behavior is automatically skipped when the user has prefers-reduced-motion enabled (WCAG 2.2 SC 2.3.3)
• Event listeners are cleaned up when transcript is destroyed (registered via a per-player AbortController)
• No performance impact when transcript is not visible

Accessibility Features

Keyboard Accessible - Full keyboard navigation
ARIA Labels - Proper role and aria-label attributes
Focus Management - Logical focus order with a focus trap while the window is open; focus returns to the toggle on close
Screen Reader Friendly - Semantic HTML structure
High Contrast - Respects system color preferences
Reduced Motion - Auto-scroll honors prefers-reduced-motion
Touch Friendly - Touch targets at or above the WCAG 2.2 AA 24×24 CSS-pixel minimum (SC 2.5.8)

Best Practices

1. Always provide captions - Even auto-generated captions are better than none
2. Use descriptive labels - Help users identify track languages
3. Test on mobile - Ensure transcript is readable on small screens
4. Consider positioning - Transcript next to video works well on desktop
5. Style consistently - Match your site's design while maintaining readability

Demo

See working examples:

• demo/demo.html - Basic transcript usage
• demo/sign-language-demo.html - Transcript with sign language video

Built with Vanilla JavaScript by Matthias Peltzer
